BASIC INFO
Features
>Aging resistance, radiation resistance
>Good Thermostability
>Seawater corrosion resistance
>Low temperature resistant
>Good flame-retardant
>Self-extinguishing
>Acid resistance and alkali resistance
Application
Widely used in the chemical tanker, oil tanker mooring line, rowing antenna lasso, motor cable, hoisting rigging in high temperature, fire protection area, etc.
Technical Data
| Size | Linear
Density ktex |
Standard
Tolerance% |
Weight | Min Breaking Strength | |||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | TON | ||
| 6 | 3/4 | 29 | ±10 | 6.4 | 1.95 | 19 | 1.94 |
| 8 | 1 | 52 | ±10 | 11.4 | 3.49 | 35 | 3.57 |
| 10 | 1-1/4 | 80 | ±8 | 17.6 | 5.38 | 56 | 5.71 |
| 12 | 1-1/2 | 119 | ±8 | 26.2 | 8.00 | 75 | 7.65 |
| 16 | 2 | 211 | ±5 | 46.4 | 14.2 | 132 | 13.46 |
| 18 | 2-1/4 | 264 | ±5 | 58.1 | 17.74 | 175 | 17.85 |
| 20 | 2-1/2 | 325 | ±5 | 71.5 | 21.84 | 205 | 20.91 |
| 24 | 3 | 475 | ±5 | 104.5 | 32.00 | 306 | 31.21 |
| 28 | 3-1/2 | 650 | ±5 | 143.0 | 43.68 | 410 | 41.82 |
| 32 | 4 | 872 | ±5 | 192.0 | 58.48 | 525 | 53.55 |
| 36 | 4-1/2 | 1070 | ±5 | 235.4 | 72.00 | 656 | 66.91 |
| 40 | 5 | 1294 | ±5 | 285.0 | 87.00 | 825 | 84.15 |
