BASIC INFO
Aramid Rope Features:
High-temperature resistance
Anti-seawater corrosion
Low temperature resistant
Good Fire resistance
Self-extinguishing
Good acid resistance and alkali resistance
Application:
widely used in the vessel, the chemical tanker, oil tanker mooring line. fire fighting, hoisting rigging.
| Size | Linear Density ktex |
Standard Tolerance % |
Weight | Min Breaking Strength |
|||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 6 | 1/4 | 30 | ±5 | 6.6 | 2.0 | 22 | 2.5 |
| 8 | 5/16 | 52 | ±5 | 11.4 | 3.5 | 36 | 3.8 |
| 10 | 13/32 | 81 | ±5 | 17.8 | 5.4 | 58 | 5.9 |
| 12 | 15/32 | 120 | ±5 | 26.4 | 8.1 | 78 | 8.0 |
| 16 | 5/8 | 212 | ±5 | 46.4 | 14.2 | 135 | 13.8 |
| 18 | 23/32 | 265 | ±5 | 58.3 | 17.8 | 177 | 18.1 |
| 20 | 13/16 | 328 | ±5 | 72.2 | 22.0 | 212 | 21.6 |
| 24 | 15/16 | 480 | ±5 | 105.6 | 32.3 | 310 | 31.6 |
| 28 | 1-1/8 | 653 | ±5 | 143.7 | 44.0 | 415 | 42.3 |
| 32 | 44 | 870 | ±5 | 191.4 | 58.5 | 517 | 52.73 |
| 36 | 4-1/2 | 1060 | ±5 | 233.2 | 71.2 | 650 | 66.3 |
| 0 | 5 | 1305 | ±5 | 287.0 | 87.7 | 803 | 81.90 |
| 44 | 5-1/2 | 1575 | ±5 | 346.5 | 105.8 | 979 | 99.85 |
| 48 | 6 | 1880 | ±5 | 413.6 | 126.3 | 1140 | 146.88 |
| 56 | 7 | 2560 | ±5 | 563.2 | 172.0 | 1561 | 159.22 |
| 64 | 8 | 3350 | ±5 | 737.0 | 225.0 | 2050 | 209.1 |
| 72 | 9 | 4245 | ±5 | 934.0 | 285.3 | 2640 | 269.28 |
| 80 | 10 | 5233 | ±5 | 1151.0 | 352.0 | 3190 | 325.38 |
| 88 | 11 | 6335 | ±5 | 1394.0 | 426.0 | 3796 | 387.19 |
| 86 | 12 | 7550 | ±5 | 1661.0 | 507.4 | 4420 | 450.81 |
| 110 | 13-3/4 | 9350 | ±5 | 2057.0 | 628.4 | 5560 | 567.12 |
