BASIC INFO
Features：
Alkali resistance
High resilience
Good wear-resisting performance
Good UV protection performance
Application:
Widely used in large ships, warships, towing, oil exploration, fisheries, mining and many other fields.
| Size | Linear Density ktex |
Standard Tolerance % |
Weight | Min Breaking Strength |
|||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 20 | 2-1/2 | 245 | ±5 | 53.9 | 16.5 | 77 | 7.9 |
| 24 | 3 | 355 | ±5 | 89.1 | 23.9 | 111 | 11.3 |
| 28 | 3-1/2 | 485 | ±5 | 106.7 | 32.6 | 160 | 16.3 |
| 32 | 4 | 630 | ±5 | 138.6 | 42.3 | 200 | 20.4 |
| 36 | 4-1/2 | 800 | ±5 | 176.0 | 53.8 | 259 | 26.4 |
| 40 | 5 | 990 | ±5 | 217.8 | 66.5 | 300 | 31.0 |
| 44 | 5-1/2 | 1200 | ±5 | 264.0 | 80.6 | 360 | 36.7 |
| 48 | 6 | 1420 | ±5 | 312.4 | 95.4 | 420 | 42.8 |
| 52 | 6-1/2 | 1660 | ±5 | 365.2 | 111.6 | 485 | 49.5 |
| 56 | 7 | 1930 | ±5 | 424.6 | 129.7 | 534 | 54.5 |
| 60 | 7-1/2 | 2210 | ±5 | 486.2 | 149.0 | 610 | 62.2 |
| 64 | 8 | 2520 | ±5 | 554.4 | 169.3 | 680 | 69.4 |
| 72 | 9 | 1390 | ±5 | 701.8 | 214.4 | 843 | 86.0 |
| 80 | 10 | 3940 | ±5 | 866.8 | 265.0 | 1030 | 105.0 |
| 88 | 11 | 4770 | ±5 | 1049.4 | 321.0 | 1280 | 130.6 |
| 96 | 12 | 5680 | ±5 | 1249.6 | 382.0 | 1480 | 151.0 |
| 104 | 14 | 6660 | ±5 | 1465.2 | 448.0 | 1770 | 180.5 |
| 112 | 14 | 7720 | ±5 | 1698.4 | 519.0 | 2015 | 205.3 |
| 120 | 15 | 8870 | ±5 | 1951.4 | 596.1 | 2310 | 235.6 |
| 128 | 16 | 10100 | ±5 | 2222.0 | 679.0 | 2650 | 270.3 |
| 136 | 17 | 11400 | ±5 | 2508.0 | 766.1 | 2895 | 295.3 |
| 144 | 18 | 12800 | ±5 | 2816.0 | 860.2 | 3252 | 332.0 |
| 152 | 19 | 14300 | ±5 | 3146.0 | 961.0 | 3569 | 364.0 |
| 160 | 20 | 15800 | ±5 | 3476.0 | 1062.0 | 3908 | 399.0 |
