BASIC INFO
Features:
Good thermostability
Anti-aging,UV resistance
Stable chemical performance,strong acid resistance
Tensile strength, good rigidity, not easy deformation
Good wear resistance, high intensity, long service life
Good UV protection performance(UPF）
Application:
It is mainly used for mooring ships, ocean transportation, port terminals, national defense,
mine traction, etc
| Size | Linear
Density ktex |
Standard
Tolerance % |
Weight | Min Breaking Strength | |||
| Diameter | Cir（inch） | KGS/220M | LBS/100FT | KN | Ton | ||
| 20 | 2-1/2 | 304 | ±5 | 66.9 | 20.4 | 88 | 9.0 |
| 24 | 3 | 441 | ±5 | 97.0 | 29.6 | 125 | 12.8 |
| 28 | 3-1/2 | 594 | ±5 | 130.7 | 40.0 | 177 | 18.0 |
| 32 | 4 | 778 | ±5 | 171.2 | 52.3 | 212 | 21.2 |
| 36 | 4-1/2 | 982 | ±5 | 216.0 | 66.0 | 265 | 27.0 |
| 40 | 5 | 1215 | ±5 | 267.3 | 81.7 | 319 | 32.5 |
| 44 | 5-1/2 | 1468 | ±5 | 323.0 | 98.7 | 378 | 38.6 |
| 48 | 6 | 1750 | ±5 | 385.0 | 118.0 | 445 | 45.4 |
| 52 | 6-1/2 | 2050 | ±5 | 451.0 | 138.0 | 519 | 52.9 |
| 56 | 7 | 2380 | ±5 | 524.0 | 160.0 | 590 | 60.2 |
| 60 | 7-1/2 | 2730 | ±5 | 600.3 | 183.5 | 660 | 67.3 |
| 64 | 8 | 3110 | ±5 | 684.2 | 209.0 | 765 | 78.0 |
| 72 | 9 | 3930 | ±5 | 865.0 | 264.1 | 953 | 97.2 |
| 80 | 10 | 4580 | ±5 | 1067.0 | 326.0 | 1168 | 119.1 |
| 88 | 11 | 5870 | ±5 | 1291.4 | 394.5 | 1402 | 140.0 |
| 96 | 12 | 6990 | ±5 | 1538.0 | 470.0 | 1660 | 169.3 |
| 104 | 14 | 8200 | ±5 | 1804.0 | 551.0 | 1906 | 194.4 |
| 112 | 14 | 9500 | ±5 | 2090.0 | 638.4 | 2175 | 220.0 |
| 120 | 15 | 10900 | ±5 | 2398.0 | 733.0 | 2490 | 254.0 |
| 128 | 16 | 12400 | ±5 | 2728.0 | 833.3 | 2840 | 289.7 |
| 136 | 17 | 14000 | ±5 | 3080.0 | 941.0 | 3185 | 325.0 |
| 144 | 18 | 15700 | ±5 | 3454.0 | 1055.1 | 3560 | 363.1 |
