BASIC INFO
Polyethylene Rope Feature:
Acid resistance,alkali resistance ,Oxidizing resistance
Anti-UV, bending resistance
Fatigue resistance
Low temperature resistance
Application:
Widely used for berthing and mooring line. the sling, towing, national defense,Marine oil ,ocean transportation,and other fields.
| Size | Linear
Density ktex |
Standard
Tolerance % |
Weight | Min Breaking Strength | |||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 28 | 3-1/2 | 490 | ±5 | 122.0 | 32.9 | 675.0 | 68.90 |
| 32 | 4 | 621 | ±5 | 154.0 | 41.7 | 873.0 | 89.00 |
| 36 | 4-1/2 | 765 | ±5 | 190.0 | 51.4 | 1094.0 | 111.6 |
| 40 | 5 | 865 | ±5 | 215.0 | 58.1 | 1337.7 | 136.45 |
| 44 | 5-1/2 | 1060 | ±5 | 264.0 | 71.2 | 1605.0 | 164.00 |
| 48 | 6 | 1250 | ±5 | 311.0 | 84.0 | 1892.0 | 193.00 |
| 52 | 6-1/2 | 1460 | ±5 | 363.0 | 98.1 | 2200.0 | 224.40 |
| 56 | 7 | 1690 | ±5 | 420.0 | 113.6 | 2527.4 | 257.80 |
| 60 | 7-1/2 | 1930 | ±5 | 480.0 | 129.7 | 2873.5 | 293.10 |
| 64 | 8 | 2200 | ±5 | 547.0 | 147.9 | 3239.0 | 330.40 |
| 72 | 9 | 2780 | ±5 | 691.0 | 187.0 | 4020.0 | 410.04 |
| 80 | 10 | 3430 | ±5 | 853.0 | 231.0 | 4858.0 | 495.50 |
| 88 | 11 | 4170 | ±5 | 1037.0 | 280.0 | 5728.0 | 584.30 |
| 96 | 12 | 4970 | ±5 | 1236.0 | 334.0 | 6670.0 | 680.30 |
| 104 | 14 | 5800 | ±5 | 1442.0 | 390.0 | 7216.0 | 736.00 |
| 112 | 14 | 6730 | ±5 | 1673.0 | 452.3 | 8321.0 | 848.70 |
| 120 | 15 | 7720 | ±5 | 1919.0 | 519.0 | 9487.0 | 967.70 |
| 128 | 16 | 8790 | ±5 | 2185.0 | 591.0 | 10723.0 | 1093.80 |
| 136 | 17 | 9920 | ±5 | 2466.0 | 667.0 | 11989.7 | 1222.95 |
| 144 | 17-1/2 | 10510 | ±5 | 2613.0 | 706.0 | 12623.0 | 1287.50 |
