BASIC INFO
Features:
Acid resistance,alkali resistance ,Oxidizing resistance
Anti-UV, bending resistance
Fatigue resistance
Low temperature resistance
Application:
Widely used for berthing and mooring line, the lifting sling, towing, national
defense, Marine oil, ocean transportation, and other fields
| Size | Linear Density ktex |
Standard Tolerance % |
Weight | Min Breaking Strength |
|||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 4 | 1/2 | 10 | ±10 | 2.5 | 0.67 | 16.0 | 1.63 |
| 6 | 1/4 | 24 | ±10 | 6.0 | 1.61 | 43.0 | 4.39 |
| 8 | 5/16 | 39 | ±10 | 9.7 | 2.62 | 67.3 | 6.86 |
| 10 | 13/32 | 62 | ±8 | 15.4 | 4.17 | 97.0 | 9.89 |
| 12 | 15/32 | 89 | ±8 | 22.0 | 5.98 | 134.0 | 13.67 |
| 14 | 9/16 | 121 | ±8 | 30.1 | 8.13 | 177. | 18.10 |
| 16 | 5/8 | 158 | ±5 | 39.3 | 10.62 | 230.0 | 23.46 |
| 18 | 23/32 | 201 | ±5 | 50.0 | 13.51 | 287.8 | 29.35 |
| 20 | 2-1/2 | 246 | ±5 | 61.0 | 16.53 | 353.0 | 36.00 |
| 22 | 2-3/4 | 307 | ±5 | 76.3 | 20.63 | 424.0 | 43.25 |
| 24 | 3 | 365 | ±5 | 90.7 | 24.53 | 500.0 | 51.00 |
| 28 | 3-1/2 | 490 | ±5 | 122.0 | 32.93 | 675.0 | 68.90 |
| 32 | 4 | 621 | ±5 | 154.4 | 41.73 | 873.0 | 89.00 |
| 36 | 4-1/2 | 765 | ±5 | 190.1 | 51.40 | 1094.0 | 111.6 |
| 40 | 5 | 865 | ±5 | 215.0 | 58.13 | 1337.7 | 136.56 |
| 44 | 5-1/2 | 1060 | ±5 | 264.0 | 71.23 | 1605.0 | 164.00 |
| 48 | 6 | 1250 | ±5 | 311.0 | 84.00 | 1892.0 | 193.00 |
| 52 | 6-1/2 | 1460 | ±5 | 363.0 | 98.10 | 2200.0 | 224.40 |
| 56 | 7 | 1690 | ±5 | 420.0 | 113.58 | 2527.4 | 257.80 |
| 60 | 7-1/2 | 1930 | ±5 | 478.0 | 129.7 | 2873.5 | 293.10 |
| 64 | 8 | 2200 | ±5 | 547.0 | 147.85 | 3239.0 | 330.40 |
| 72 | 9 | 2780 | ±5 | 691.0 | 186.83 | 4020.0 | 410.04 |
| 80 | 10 | 3430 | ±5 | 853.0 | 230.51 | 4858.0 | 495.50 |
| 88 | 11 | 4170 | ±5 | 1037.0 | 280.24 | 5728.0 | 584.30 |
| 96 | 12 | 4970 | ±5 | 1236.0 | 334.00 | 6670.0 | 680.30 |
| 104 | 13 | 5800 | ±5 | 1442.0 | 389.80 | 7216.0 | 736.00 |
| 112 | 14 | 6730 | ±5 | 1673.0 | 452.30 | 8321.0 | 848.70 |
| 0120 | 15 | 7720 | ±5 | 1919.0 | 518.80 | 9487.2 | 967.70 |
| 128 | 16 | 8790 | ±5 | 2185.0 | 590.73 | 10723.0 | 1093.80 |
| 136 | 17 | 9920 | ±5 | 2466..0 | 666.70 | 11989.7 | 1222.95 |
| 140 | 17-1/2 | 10510 | ±5 | 2613.0 | 706..30 | 12623.0 | 1287.50 |
